Takeuchi TL130 Crawler Loader Workshop Manual

Description

Takeuchi TL130 Crawler Loader Workshop Manual PDF
Make: Takeuchi
Model: TL130
Pages: 712
Format: PDF
Size: 35.8 mb
Language: English
Requirements: Adobe PDF Reader & WinZip
Compatibility: All Versions of Windows & Mac/IPAD/IOS

This manual is intended for persons who engage in maintenance operations, and explains procedures for disassembly and reassembly of the machine, check and maintenance procedures,maintenance reference values, troubleshooting and outline specifications, etc.

Model: TL130

Serial No. 2130004

Table of contents:

1. GENERAL
2. SPECIFICATIONS
3. MACHINE CONFIGURATION
4. HYDRAULIC UNITS
5. TROUBLESHOOTING
6. ENGINE
