Kubota KX080-4 Excavator Workshop Service Manual

Description

Kubota KX080-4 Excavator Workshop Service Manual
Pages: 519
Format: PDF
Size: 35 mb
Language: English
Requirements: Adobe PDF Reader & WinZip
Compatibility: All Versions of Windows & Mac/IPAD

This Workshop Manual provides service personnel with information about the mechanisms, service and maintenance of the construction machinery. This Workshop Manual is divided into 3 sections, General, Mechanisms and Service.

Contents:

I General
II Machine body
• Mechanism Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .II-M-1
• Service Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .II-S-1
V Electrical System
IV Hydraulic System
• Mechanism Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IV-M-1
• Service Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IV-S-1
III Engine
• Mechanism Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .III-M-1
• Service Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .III-S-1
IV Orbitrol motor ; structure & function
